How to Tackle Verilog-Based High-Level C Translation Assignments for FPGA Systems

Analyzing the Source C Code

In many assignments, the provided C code includes operations like:

• Calling sub-functions (mem_init_rand, rot_right)
• Reading and writing memory values
• Utilizing nested loops and conditionals
• Tracking values across multiple iterations
• Returning a final result

In the example shared, the following characteristics are noticeable:

• Memory initialization uses a pseudo-random function.
• An element at memory address 5 is set explicitly to 42.
• Iterative logic is used to compare, rotate, and update memory values.
• Several helper functions must be created to reflect software abstractions.

Understanding what the C code intends to do is step one. Creating a high-level flowchart of the software logic before hardware translation can save hours of debugging.

Mapping Software Constructs to Verilog

Verilog does not support dynamic constructs like functions or flexible memory allocation. You must create equivalents:

• Loops become FSMs that track loop counters and step through states.
• Functions like abs(), max(), and rot_right() become hardware modules or inline combinational logic.
• Arrays become RAMs—usually single-port on-chip memory blocks in DE1-SoC assignments.
• Return values become output wires updated at the end of FSM sequences.

When reading such a C function, treat every operation as a transformation that must be orchestrated via state transitions and signals.

Navigating the Wrapper and I/O Requirements

Assignments like these often provide a wrapper module (e.g., ex4_wrapper.v) to:

• Handle clk, rst, start, and done signals
• Interface with a single on-chip RAM
• Control the timing and sequencing of your design

This wrapper isn’t just for simulation—it’s your gateway to hardware. Understand it thoroughly to determine where and how your custom FSM and logic modules should plug in.

Crafting a Modular Verilog Design

Once you understand the assignment logic, begin crafting a solution around modularity, state design, and reuse.

Designing Initialization and Memory Logic

Memory access is the backbone of most Verilog assignments, and how you design your memory interface can determine success or failure.

Pseudo-Random Memory Initialization

The function mem_init_rand in the original C initializes memory using a pseudo-random generator. In Verilog:

• Use a Linear Feedback Shift Register (LFSR) for generating random values.
• Write memory sequentially using a start-controlled FSM.
• Ensure that address 5 always gets overwritten with the hardcoded value 42.

LFSRs are hardware-friendly, requiring little logic and no additional memory. Build your FSM to iterate through addresses 0 to 127, writing values generated by the LFSR, with a special condition to force the 42 at address 5.

Rotational and Conditional Operations

Functions like rot_right and abs may appear simple but must be hardware-friendly:

• rot_right: Create an FSM that right-shifts bits for a fixed number of iterations.
• abs: Use combinational logic with conditional checks.
• max/min: One-liner modules or inline logic in your FSM states.

These functions should be synthesized carefully to avoid unnecessary hardware bloat. Inline simple logic, and isolate more complex tasks in their FSMs for better debugging.

FSM-Controlled Loop Operations

Loops like:

c CopyEdit while (idx < x) { ... for (i = 1; i < y; i++) { ... } }

must be transformed into FSM sequences. Define counters like idx and i as regs, and build a nested FSM structure:

• Outer FSM for the while-loop
• Inner FSM for the for-loop

Use flags and signals to manage transitions between FSM states, and always respect the timing of RAM accesses (1-cycle read latency, for instance).

Handling Arithmetic and Comparison Functions

Your solution will need helper modules for functions like add_min_max, max, and abs. Here’s how to organize them:

Arithmetic Units

Use clean, always-combinational logic for:

verilog CopyEdit assign result = (a > b) ? a : b;

Avoid using behavioral arithmetic unless synthesis directives support them efficiently. Always test these blocks in isolation.

Control Integration

All helper modules should be orchestrated by the main FSM. Whether pipelined or sequential, they must handshake via start and done signals to fit the overall flow.

Testing, Debugging, and Simulation

After coding, your design needs verification to ensure accuracy.

Developing a Comprehensive Testbench

A good testbench does more than apply inputs:

• Initialize clk, rst, start
• Set memory to known or pseudo-random values
• Apply test values for in1 and in2
• Wait for done to go high
• Verify output1 matches expected value

For example, simulate inputs like in1 = 10, in2 = 7 and log how output1 changes with and without the conditionals triggering.

Using Waveform Debugging Tools

Simulators like ModelSim or GTKWave allow step-through verification:

• Verify memory values during init
• Track FSM state transitions
• Check counters idx, i, and how they trigger memory reads/writes
• Observe done and output1 transitions

These visual cues will expose hidden bugs—like skipped states, incorrect memory addressing, or misconfigured FSM resets.

Managing Synthesis and Hardware Constraints

Quartus Compilation

• Import your design into Quartus.
• Attach the ex4_wrapper.v.
• Compile, resolve pin constraints if deploying to hardware.

Timing and Area Reports

Once compiled, evaluate:

• Execution time: How many clock cycles from start to done?
• Area utilization: How many logic elements (LEs) and memory bits are used?
• DSPs: Make sure you're not using more than needed (usually 0 for basic operations).

Final Checks and Submission Tips

These last steps ensure your assignment submission is polished, professional, and most importantly—correct.

Performance Estimation

Your assignment may require estimating execution time. Do this by:

• Counting FSM clock cycles manually or via simulation
• Multiplying total cycles by 20ns (for 50MHz system clock)
• Reporting cycle count and estimated time

Example:

makefile CopyEdit Cycles: 850 Time = 850 * 20ns = 17µs

If loops are data-dependent, simulate for multiple input values and report an average or range.

Optimization Opportunities

If you have spare time, consider refining your design:

• FSM Simplification: Fewer states = less area and better timing.
• Combinational Logic Consolidation: Reduce stages if not required.
• Signal Naming and Documentation: Clear variable names help graders understand your logic.

Submission Checklist

• Clean, commented code
• Modular and reusable helper functions
• Working testbench with multiple test cases
• Screenshot of simulation waveform
• Quartus area and timing report
• README explaining FSM design and results

Conclusion: Becoming Confident in C-to-HDL Translation

Solving Verilog assignments that mirror C logic isn’t about converting line-by-line—it’s about thinking like a hardware designer. When you can break software logic into FSMs, modular components, and predictable memory interactions, you unlock the power to build real, working systems.

Here’s a recap for success:

• Understand software logic fully before hardware translation
• Design in modules, especially for nested loops and conditional logic
• Simulate rigorously before attempting synthesis
• Always validate memory behavior, FSM correctness, and output logic
• Report performance metrics thoughtfully

These are the skills that don’t just get you marks—they get you ready for a real-world career in FPGA, embedded systems, and digital architecture.
